- Size: 110mm*130mm
- Place of Origin: shenzhen china
- Brand Name: Vstarcam
- Model Number: C42
- Weight: 0.755 kg
Product Abstract:
Eye4Life C42 IP Camera software limit controlled PT rotator ensures low malfunction rate; One Key Wifi configuration.supports 4 online visitors simultaneously
- Size: 110mm*130mm
- Place of Origin: shenzhen china
- Brand Name: Vstarcam
- Model Number: C42
- Weight: 0.755 kg
Product Description
Model: C42
Features
Function Feature
software limit controlled PT rotator ensures low malfunction rate; One Key Wifi configuration.
System
Operation System
Embedded Linux
System Security
Three level user authority management
Online Visitor
supports 4 online visitors simultaneously
DDNS
Free DDNS
Protocol
ONVIF 2.4, high interoperability
Processor
Hisilicon processor, integrated ARM926 @Max. 440MHz and high-speed video co-processor.
Reset
Long press for 15 seconds to restore back to factory settings
Image Capturing
Image Sensor
1/4 inch 720P progressive CMOS sensor
Sensor Function
AWB, AGC, AE supported
Imaging Area
4.40mm×2.52mm
SNR
≥41dB
Minimum illumination
0.8Lux/F1.4 (full color mode), 0.3Lux/F1 (black white mode)
Lens/viewing angle
3.6mm@F1.4/56.14°
Night Vision
dual IR-Cut filter automatic switch, 11pcs 850nm IR LEDs, 10m night vision distance
IR Control
IR turned on: night vision view enabled, infrared Ray, ICR auto detect.
IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.Video
Compression standard
H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline
Video Coding
multiple video stream: 720P@24fps VGA@30fps QVGA@30fps 720P @1fsJPEG screenshot
Resolution
720p/VGA/QVGA
Bit Rate
CBR/VBR,output bit rate is 128~4096kbps
Maximum Frame rate
25fps
Image Adjustment
brightness, contrast, saturation, chroma are adjustable
Audio
Input
built-in 48db microphone
Output
built-in speaker (8Ω1W)
Sampling Frequency Bit Width
8KHz/16bit
Compression Standard/Bit Rate
ADPCM/32kbps
Network
Ethernet Socket
10Mbps/100Mbps self adaptable/RJ45 interface
Internet Protocol
TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,ŒP2P etc.
Wireless Internet
WiFi802.11b/g/n
Antenna
3dBi antenna, stronger signal, more stable
Protocol
one key Wifi confugration, no network cable ever needed
Storage
Storage
local storage/client terminal storage, maximum 64G storage
Interface
Micro SD
Pan/Tilt Rotation
Angle
Pan 355°/Tilt 80°
Pre-set Position
15 pre-set positions
Limit Position
software limited controlled rotator ensures more accurate pre-set positions and lower malfunction.
Alarm
Alarm Detection
motion detection
Alarm Action
E-mail image /FTP image upload/smart phone APP action
Physical Parameters
Rated Voltage
DC5/2A±0.3V
Power comsumption
3.0W(with IR LEDs on)
Working Environment
Working Environment: -20~70℃, working humidity: 90%
Gross Weight
755g(subject to final products)
Housing Material
ABS plastic
Camera Size
110mm*130mm
Installation
wall mounting, ceiling mounting
