Features

●H.264 compression format，1080P high-resolution；
●3.6mm lens，night view distance is 20m；
●Support mobile phone background alarm push；
●onvif 2.4 protocol，support the market mainstream NVR；
●Support multi-stream output simultaneously；
●IP66；
●Support Windows、iPhone、ipad and Android phone；

category

type

parameters

System

Online user

Support 4 account access at the same time

plug and play

P2P connection

Domain name

Offer DDNS freely

system

Win98 SE/ME/2000/XP,Vista,iPhone iOS 5.0\android 4 or above

control protocol

ONVIF 2.4，Universal agreement, enhance the interoperability of the product

Processor

Hi3516C

Collection

White balance

Auto adjust

BLC

Auto adjust

gain control

Auto adjust

SNR

≥39dB

Lowest illumination

0.8Lux/F2.1（colorful）,0.3Lux/F2.1（black and white）

lens/view angle

3.6mm ，80°

Night view

Double filter（IR-cut）auto switching，4pcs 850nmΦ42Mil infrared light，night view distance 20m.

IR

Double filter（IR-cut）auto switching

Video

resolution

1080P/720P/360P

code rate

VBR dynamic stream，range:128～4096Kbps

max Frame rate

1080P/25fps 720P/25fps VGA/25fps

Image adjustment

brightness、contrast、saturation

Network

RJ45

support

protocol

TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP，P2P,

WiFi

WiFi 802.11b/g/n

Alarm

alarm detection

Motion detection

alarm action

iamge E-mail/FTP upload/phone app action

Storage

storage mode

local storage，128G Micro SD card，alarm pre-record

connector

Micro SD

Physical index

voltage

DC12V/3A±0.3V

Installation

wall mount, ceiling

Power consumption

Rated power：3.5Ｗ(IR light open)

Working environment

temperature：-10～50℃，humidity<90%

Overall material

waterproof, aluminum alloy

weight

G.W：1117g（note：subject to the actual product）

Package size

245*200*120mm

（note：subject to the actual product）
