- Size: 185mm x77mm x77mm
- Place of Origin: shenzhen
- Brand Name: Vstarcam
- Model Number: C17
- Weight: 0.480 kg
System | Operation system | C17 Embedded Linux OS |
Online visitor | Support 4 visitors at the same time | |
Image Capture | Image sensor | 1/4 inch 720p Progressive Scan CMOS |
Minimum Illumination | 0.3~0.5Lux(Color mode), 0Lux(B&W mode) | |
Lens | ||
View Angle | 71.1°（diagonal） | |
Nightvision | Dual Filter,IR-Cut，18pcs 850nm SMD IR LED， IR irradiation distance:10~15m | |
Video | Encode format | H.264 main profile@levels:4.0/Motion-JPEG |
Three Stream | Main Stream:720p(1280×720)@25fps Sub Stream:360p(640X360)@25fps Third Stream:180p(320X180)@10fps | |
Bit Rate | 128～4096kbps | |
Maximum frame rate | 25fps | |
Image adjustment | Contrast、Brightness、Saturation、Hue | |
Audio | N/A | |
Network | Ethernet | 10Base-T / 100Base-TX, RJ45 connector |
Protocols | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc | |
Wireless LAN | IEEE802.11b/g/n | |
Wireless LAN Frequency | 2.4~ 2.4835GHz | |
Wireless LAN security | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
Pan-Tilt | N/A | |
Memory | Socket | TF Push-push socket,Maximum support 128GB |
Alarm | Alarm Trigger | Motion detection |
Physical Environmental | Rated voltage | DC12V±5% |
Power consumption | Related power:6W(IR on) | |
Operating condition | Temperature:-10～50℃,humidity:＜90% | |
Weight | Gross：TBD g(Note: in kind prevail) | |
Package size | 204*99*122mm(L×W×H) |
